MELAMINE HMR MDF

Melamine HMR MDF is a high-quality moisture resistant decorative panel made from HMR (High Moisture Resistant) MDF core laminated with melamine-impregnated paper under high temperature and pressure. It combines excellent moisture resistance with a durable and decorative surface finish, making it ideal for use in humid environments.

Compared with standard MDF, Melamine HMR MDF offers better dimensional stability and improved resistance to humidity, while still maintaining a smooth, attractive, and ready-to-use surface.


Key Features:

High Moisture Resistance (HMR Core) – Suitable for humid environments

Durable Melamine Surface – Available in wood grain, solid colors, and textures

Smooth & Flat Finish – Ideal for modern furniture design

Stable Structure – Reduced swelling and deformation

Ready-to-Use Panel – No painting or additional finishing required


sku:HMR MDF
+008615853930865 +0086 15853930865

Description

                               PUSEN MELAMINE HMR MDF BOARD


Product NameMelamine Moisture Proof Mdf Board
Other namesMoisture Resistant/Water-Resistant/Moisture-Resistant/Moisture-Repellent/Anti-Moisture MDF Board、HMR/MR MDF、Green MDF、Black HDF、Black CDF
Density ClassGreen MDF:710-880 kg/m³,Black HDF:880-1000 kg/m³,Black CDF:1000 kg/m³ or higher
Raw Material GradeA1 grade (pure untreated wood), A2 grade (clean recycled wood), A3 grade (recycled wood without chemical preservatives)
SizeCommonly used: 1220x2440mm (4’x8′),Others: 915 mm x 1830 mm (3’x6′), 915x2135mm (3’x7′), 1200x2400mm (3.9’x7.9′), 1200 x 3600mm (3.9’x11.8′), 1220×2745 mm (4’x9′), 1220x2745mm (4’x10′), 1525 mm x 3050 mm (5’x10′), 1800 x 3600 mm (5.9’x11.8′), 1830x2440mm (6’x8′), 1830x2745mm (6’x9′), 2135x 3050mm(7’x10′),2440x3660mm(8’x10′),Upon To Request
Thickness2.5mm-30mm, regular sizes 2.5 (3/32″), 3 (1/8″), 4 (5/32″), 5 (3/16″), 6 (1/4″), 7 (9/32″), 8 (5/16″), 9 (3/8″), 10 (13/32″), 11 (7/16″), 12 (15/32″), 13 (1/2″), 14 (9/16″), 15 (19/32″), 16 (5/8″), 18 (11/16″), 19 (3/4″), 20 (25/32″), 21 (13/16″), 22 (7/8″), 24 (15/16″), 25 (1″) mm/inch, customizable upon request
CorePoplar, Combi, Pine, Eucalyptus/Hardwood Wood fiber
Production Line TypeMulti-Opening Press Line(multi-layer line)/Continuous Flat Press Line(Siempelkamp)
GlueE0 Glue,E1 Glue,E2 Glue,CARB P2 Glue,MDI(Methylene Diphenyl Diisocyanate) Glue
Moisture Content5% – 11%
Dimensional ToleranceThickness: ±0.2mm or stricter, Length & Width: ±2mm/m, Diagonal Difference: ≤2mm/m
Water absorption expansion rate after 24hWater absorption rate is about 11%, thickness expansion rate is 5-9%
Internal Bond Strength – IB0.5 – 1.2 N/mm² or higher
Modulus of Rupture – MOR18 – 40 MPa or higher
Modulus of Elasticity – MOE2000 – 3500 MPa or higher
Thickness Swelling after 24hStandard Board ≤ 15%, Moisture Resistant Board (MRMDF) ≤ 10%
Screw Holding Strength – Face and EdgeFace Screw Holding > 1200 N
Edge Screw Holding > 1000 N
Surface Bonding Strength1.0 – 1.5 N/mm² or higher
MOQ42CBM/40’GP.50CBM/40’HQ
PackingInner Packing:0.2mm Thickness Plastic Bag,Outer Packing:Pallet With Carton And Strapped With Steel Tape
DeliveryWithin 20 days After Confirm The Order
DaysPaymentTT,L/C,DP,MONEYGRAM,WESTERN UNION,PAYPAL
UsageKitchen cabinets, bathroom cabinets, laundry and utility room furniture; washroom partitions, display cabinets, wall panels for restaurants, retail shops, gyms, spas and medical facilities.
Capacity10000CBM PER MONTH
Standard Compliance & CertificationsEN317,EN 335, EN 622-5, ANSI A208.2, JIS A 5905, ASTM E1333, ISO 9001, ISO 14001, FSC, PEFC, CARB, CE Mark, BIS etc.


How PUSEN Controls the Quality of Melamine HMR MDF

At PUSEN, we implement a strict, full-process quality control system to ensure every sheet of Melamine HMR MDF delivers excellent moisture resistance, stable structure, and premium decorative finish for furniture and interior applications.

1. High-Quality HMR MDF Core Selection

We carefully select high moisture resistant (HMR) MDF boards with uniform density and strong internal structure. Each core is inspected for:

Only qualified HMR-grade MDF is used.

2. Strict Moisture Content Control

All MDF boards are conditioned in controlled environments to maintain stable moisture levels. This helps prevent:

3. Premium Melamine Paper Selection

We use high-quality melamine decorative paper with stable color and texture. Each batch is strictly checked for:

4. Advanced Hot Press Lamination Process

Melamine paper is laminated onto HMR MDF using precise hot press technology. We strictly control:

This ensures strong bonding, smooth surface, and no bubbling.

5. Moisture Resistance Performance Control

We ensure the HMR performance is fully maintained during production by monitoring:

6. Surface Quality & Finishing Inspection

Each board is carefully inspected for:

7. Edge & Machining Performance Control

We ensure excellent processing quality by checking:

8. Final Quality Inspection Before Shipment

Every sheet of Melamine HMR MDF undergoes strict final QC, including:

Only fully qualified products are approved for export.

 PUSEN Commitment

Through strict HMR core selection, advanced lamination technology, and full-process inspection, PUSEN ensures every Melamine HMR MDF panel delivers reliable moisture resistance, stable performance, and premium decorative quality for global customers.
